Extensometers
The GLÖTZL Extensometer is used to measure relative movements between the anchor point and the measuring head and is employed in various applications. Whether in tunneling, mining, slope stabilization, dams, or general structural monitoring – the systems can be configured to suit specific
Type GKSE
Plastic Rod Extensometer
The extensometer Type GKSE is used for measuring settlements, displacements, and deformations in:
- Tunnel construction
- Mining
- Slope stabilization
- Dam construction
- Subsurface monitoring
- Structural monitoring
Type GKTE
Fiberglas Rod Extensometer
The extensometer GKTE is used for measuring relative movements between anchor point and measuring head. Specifically designed for tunnel and cavern construction, this extensometer is developed for quick installation.
Type GDEX
Wire Extensometer
The wire extensometer is used for movement and convergence measurement in open terrain between ground and rock joints, as well as between building components.
Type SSKE40
Heavy Stationary Convergence Equipment
The heavy stationary convergence measurement device consists of solid, interlocking steel tubes. The movement of these parts is detected by displacement transducers and recorded as an electrical signal.
Type SSDE60
Heavy Stationary Strain Measuring Device
The SSDE 60 is used for monitoring movements or building cracks, expansion joints in bridge structures, or displacements of structural segments over a larger distance.
Type MA
Measuring Anchor MA
On request
Type SMA
Measuring Anchor for Swellex
When using the SWELLEX anchoring system in tunnel construction, we have developed this measuring anchor for measurement support.
Type ML
Magnetic Settlement Plumb
Magnetic settlement probes are used for the simple, fast, and reliable measurement of settlements in inclinometer casings, special monitoring casings for settlement measurement, or piezometer casings.
Type BGKM
Convergence Measuring Device (german)
The convergence measurement device is a precision instrument for measuring changes in length during displacements and deformations.
Type MFS
Mechanical Fissurometer for Remote Monitoring in Rock
The distance rock spike, Type MFS 20/3, is used to detect rock movements in horizontal and vertical directions.
Type GWW 30
Displacement Transducer
The displacement transducer GWW 30 is used for the electrical remote transmission of the measured value and is screwed directly onto the measuring head of the plastic rod extensometer using a threaded coupling.
Type GWD30/35
Displacement Transducer
The displacement transducers of the GWD 35 series are intended for installation in boreholes or other inaccessible areas of application.
Type GWD 22
Displacement Transducer
The displacement transducers of the GWD 22 series are intended for installation in boreholes or other inaccessible areas of application.
Type GWO 22/GWG 22
Displacement Transducer
The displacement transducers of the GWO 22 and GWG 22 series are intended for installation in boreholes or other inaccessible areas of application. In the probe model GWG, the housing is protected against the ingress of dust and liquids by means of a radial shaft seal.
Type GWD 10
Displacement Transducer
The displacement transducer GWD 10 offers high performance in a very compact design. It is primarily used in fissurometers and automatic measuring heads Type MA.
